產品詳情
TC40型振鏡是我司推出的一款高功率型產品:具有超高的精度、穩定性好、抗干擾能力強等特點，綜合性能達到國內外同類型產品高端技術水準。
TC40 galvanometer is a high-power product launched by our company. It has the characteristics of ultra-high precision, good stability and strong anti-interference ability. Its comprehensive performance has reached the high-end technical level of the same type of products at home and abroad.
應用領域 Application area
激光焊接 Laser welding
激光切割 Laser cutting
激光打標 Laser marking
| 掃描電機參數 Scan Motor Specifications |
TC40 |
| 非線性度 Nonlinearity |
< 3.5 mrad / 44° |
| 1%滿行程階躍響應時間 1% of full scale |
≤1.4ms |
| 跟蹤誤差時間 Tracking error |
0.75ms |
| 增益漂移 Gain error |
<50PPM/K |
| 零點漂移 Zero offset |
<10μRad./℃ |
| (預熱30分鐘后)老化漂移(8H) (after 30 min warm-up )Long-term drift(8H) |
<0.3mRad |
| 重復精度 Repeatability |
< 20μRad |
| 打標速度 Marking speed |
1000mm/s |
| 定位速度 Positioning speed |
3000mm/s |
| 掃描角度 Typical scan angle |
±0.42rad |
| 分辨率 Positioning resolution |
20μRad |
| 鏡片型號(nm) Reflection wavelength(nm) |
10600 |
| 電源要求 Power Requirements |
±15VDC,max5A each |
| 通光孔徑 Aperture |
40mm |
| 工作溫度 Operating temperature |
25℃±10℃ |
