產品詳情
TC10C型振鏡是我司推出的一款高性價比型產品:具有穩、準、快、抗干擾能力強等特點，綜合性能達到國內外同類型產品高端技術水準。
TC10C galvanometer is a high cost-effective product of our company. It has the characteristics of stability, accuracy, speed, strong anti-interference ability and so on. Its comprehensive performance has reached the high-end technical level of similar products at home and abroad.
應用領域 Application area
微加工 Micromachining
標記、標刻 Marking and marking
醫療 Medical care
光學掃描、飛行打標 Optical scanning and flying marking
| 掃描電機參數 Scan Motor Specifications |
TC10C |
| 非線性度 Nonlinearity |
< 3.5 mrad / 44° |
| 1%滿行程階躍響應時間 1% of full scale |
≤0.5ms |
| 跟蹤誤差時間 Tracking error |
0.2ms |
| 增益漂移 Gain error |
<50PPM/K |
| 零點漂移 Zero offset |
<10μRad./℃ |
| (預熱30分鐘后)老化漂移(8H) (after 30 min warm-up )Long-term drift(8H) |
<0.4mRad |
| 重復精度 Repeatability |
< 20μRad |
| 打標速度 Marking speed |
4000mm/s |
| 定位速度 Positioning speed |
10m/s |
| 掃描角度 Typical scan angle |
±0.35rad |
| 分辨率 Positioning resolution |
40μRad |
| 鏡片型號(nm) Reflection wavelength(nm) |
10600/1064/532/355 |
| 電源要求 Power Requirements |
±15VDC,max2A each |
| 通光孔徑 Aperture |
10.0mm |
| 工作溫度 Operating temperature |
25℃±10℃ |
