TC12
概述：
專注于冷結扎系統方案設計，也提供疝氣補片、穿刺器、電動吻合器等普耗的生產加工和產品升級等工業服務。
咨詢熱線：
產品詳情
TC12型振鏡是我司推出的一款高性價比型產品:具有超快的速度、超高的精度、穩定性好、抗干擾能力強等特點，綜合性能達到國內外同類型產品高端技術水準。
TC12 galvanometer is a cost-effective product launched by our company. It has the characteristics of super-fast speed, super-high precision, good stability and strong anti-interference ability. Its comprehensive performance has reached the high-end technical level of the same type of products at home and abroad.
應用領域 Application area
微加工、焊接 Microfabrication and welding
標記、標刻 Marking and marking
醫療 Medical care
光學掃描 Optical scanning
| 掃描電機參數 Scan Motor Specifications |
TC12 |
| 非線性度 Nonlinearity |
< 3.5 mrad / 44° |
| 1%滿行程階躍響應時間 1% of full scale |
≤0.6ms |
| 跟蹤誤差時間 Tracking error |
0.25ms |
| 增益漂移 Gain error |
<50PPM/K |
| 零點漂移 Zero offset |
<10μRad./℃ |
| (預熱30分鐘后)老化漂移(8H) (after 30 min warm-up )Long-term drift(8H) |
<0.4mRad |
| 重復精度 Repeatability |
< 20μRad |
| 打標速度 Marking speed |
4500mm/s |
| 定位速度 Positioning speed |
8m/s |
| 掃描角度 Typical scan angle |
±0.35rad |
| 分辨率 Positioning resolution |
20μRad |
| 鏡片型號(nm) Reflection wavelength(nm) |
10600/1064/532/355 |
| 電源要求 Power Requirements |
±15VDC,max2A each |
| 通光孔徑 Aperture |
12.0mm |
| 工作溫度 Operating temperature |
25℃±10℃ |
